SANDSTORM
™
SINGLE/DOUBLE CHAMBER INSTALLATION MANUAL | 13
INSTALLATION
14. Place the stand of the backwash controller so that it is close to the control assembly (make sure it
meets your needs for both operation and maintenance). Secure it to the concrete slab with 10 mm
spreading anchor bolts.
NOTE
There are 2 solenoid placement options:
A. All the solenoids are placed on the solenoid bracket on the controller stand.
B. Each solenoid is placed on its respective backwash valve.
Perform steps 15 and 16 on the next page according to the planned solenoid location.
