SANDSTORM
™
SINGLE/DOUBLE CHAMBER INSTALLATION MANUAL | 9
INSTALLATION
NOTE
The manifolds are supported by support legs. Each support leg should be installed immediately after
installing the part it supports. Place the support legs according to their quantity and locations in the
system installation drawings. Use the long support legs to support the inlet manifold, the medium
legs to support the backwash manifold and the short legs to support the outlet manifold.
3. Connect the inlet manifold to the backwash valves and the inlet manifold sections to each other with
grooved couplings.
4. Connect the backwash manifold to the backwash valves and the backwash manifold sections to each
other with grooved couplings.
