NetApp E Series Hardware Maintainence Manual

1. Unpack the new power supply, and set it on a level surface near the drive shelf.
Save all packing materials for use when returning the failed power supply.
2. Disconnect the power cables:
a. Open the power cord retainer, and then unplug the power cord from the power supply.
b. Unplug the power cord from the power source.
3. Locate the tab to the right of the power supply and press it towards the power supply unit.
4. Locate the handle on the front of the power supply.
5. Use the handle to slide the power supply straight out of the system.
When removing a power supply, always use two hands to support its weight.
92

NetApp E Series Specifications

General

Form Factor	2U, 4U
Drive Types	SSD
Host Interface	SAS, iSCSI, FC, IB
RAID Levels	RAID 0, 1, 5, 6, 10
Operating System Compatibility	Windows, Linux, VMware
Management Software	SANtricity
