QoS Queue
Figure 6: Advanced - QoS Queue Setup
Click the Add button to add a QoS Queue. The following screen is displayed.
Figure 7: Advanced - QoS - Add QoS Queue
The above screen allows you to configure a QoS queue entry and assign it to a specific network interface. Each of the queues can
be configured for a specific precedence. The queue entry configured here will be used by the classifier to place ingress packets
appropriately.
NOTE: Precedence level 1 relates to higher priority while precedence level 3 relates to lower priority.
QoS Classification
Figure 8: Advanced - QoS Classification Setup
Click the Add button to configure network traffic classes.
