6
Device overview
NTC-6200-03 and NTC-6200-13 models
ITEM DESCRIPTION
1 SIM card slot Insert SIM card here.
2 Two-way
terminal block
connector
Connect power source wires here. Power wires may be terminated
on the supplied terminal block and connected to a power source.
Refer to the diagram and table under Step 5 of the Installing your
device section for correct wiring of the terminal block.
Operates in the 8-40V DC range.
3 Reset button Press and hold for less than 5 seconds to reboot to normal mode.
Press and hold for 5 to 15 seconds to reboot to recovery mode.
Press and hold for 15 to 20 seconds to reset the router to factory
default settings.
4 RJ45 Ethernet
port
Connect one or several devices via a network switch here.
5 Aux antenna
socket
SMA female connector for auxiliary antenna (receive diversity).
6 Mini USB 2.0
OTG port
Provides connectivity for optional external storage or a USB Ethernet
dongle. Supplies up to 0.5A to connected device.
7 Serial port Female DB9 port supporting 9-wire RS-232, RS-485 or RS-422
(software selectable).
8 Main antenna
socket
SMA female connector for main antenna.
