Security Gateway Manual SG-3100
Note: The SG-3100 does not support NVMe drives.
The SG-3100 has two slots capable of installing M.2 SATA drives, J10 and J11.
J10 The J10 connector is for a 2280 (22mm x 80mm) M.2 SATA only.
The 80mm standoff cannot be moved.
J11 The J11 connector is for a 2242 (22mm x 42mm) M.2 SATA drive, or it can be used for a cellular card in
conjunction with a microSIM card.
The 42mm standoff is also permanent and cannot be moved.
Note: For more information on Cellular Configuration in pfSense
®
Plus software, please visit the pfSense Documen-
tation page.
This installation example uses the J11 M.2 SATA slot with a 2242 M.2 SATA Drive. The procedures to install a
2280 M.2 SATA Drive in the J10 slot is similar.
1. Turn the system over carefully to avoid scratching the top of the system. Remove the four (4) T10 Torx screws
as indicated below.
2. Turn system upright and carefully remove the cover. Set the cover off to the side and keep it upright so the top
is not scratched. Identify where the M.2 SATA drive slot is located and remove the screw from the standoff.
3. After the screw has been removed, insert the M.2 SATA drive into the slot at about a 30° angle.
© Copyright 2022 Rubicon Communications LLC 36
