1. Attach the antennas.
Attach the antennas on the threaded antenna
posts.
Position the antennas as shown.
2. Connect the modem router to a DSL
service (ADSL or VDSL).
Install the DSL microfilter between the phone
line and the phone. Use the phone cable to
connect the DSL microfilter to the DSL port on
the modem router.
3. Power on the modem router.
Wait for the Power LED
to light white.
If the Power LED does not light, press the
Power On/Off button.
Wait for the WiFi LED
to light white.
4. Check the DSL LED.
If the modem router is connected to a DSL
service, the DSL LED
lights white.
5. Connect a device.
You can use an Ethernet cable or connect with
WiFi.
To connect with WiFi, use the pre‑assigned
WiFi network name and password on the label
on the modem router.
6. Connect to the Internet.
Launch a web browser. The NETGEAR
installation assistant displays.
If you do not see the NETGEAR
installation assistant,
enter www.routerlogin.net in the
address field of the web browser. If a
login window displays, enter admin for
the user name and password for the
password.
The NETGEAR installation assistant
determines your Internet connection. If
the modem router successfully connects
to the Internet, the Internet LED
lights white.
7. Get the genie app.
Download the free genie app from
www.NETGEAR.com/genie.
Easily share media, files, and printers
on the network from your smartphone,
tablet, or laptop.
ADSL or VDSL
Internet
Power
adapter
You can use this diagram to connect your modem router or follow the detailed instructions in this booklet.
DSL
microfilter
Ethernet cable
Phone cable
Modem
router
8. Get the user manual.
You can get the user manual online at
http://downloadcenter.netgear.com
or through a link in the product’s user
interface.
Computer

Other manuals for NETGEAR D7000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR D7000 and is the answer not in the manual?

NETGEAR D7000 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
ModulationPSK
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1300 Mbit/s
Memory card slot(s)No
Ethernet LAN (RJ-45) ports5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
DSL specificationVDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management-
Firewall securitySPI, NAT
Security algorithmsWPA, WPA2-PSK, WPS
Product typeTabletop router
Product colorBlack
Housing materialPlastic
Flash memory128 MB
Internal memory256 MB
Processor cores2
Processor frequency1000 MHz
Windows operating systems supportedWindows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables includedLAN (RJ-45), Phone (RJ-11)
Supported network protocolsIPv6
Power source typeAC
Package typeBox
Weight and Dimensions IconWeight and Dimensions
Depth185 mm
Width285 mm
Height50 mm
Weight750 g
