12
Find the Best Location
If the WiFi signal is weak, the first time you join the extender network,
an arrow LED blinks for two minutes. If this happens, adjust the
position of the extender.
No arrow LEDs are lit. The extender is in a good location.
Left arrow blinks. Move the extender closer to the router.
Right arrow blinks. Move the computer or mobile device
closer to the extender.
Extender Performance
These extender LEDs indicate a WiFi connection:
WiFi signal between the router and the extender.
WiFi signal between the extender and the computer or mobile
device.
The LEDs are color coded:
• Green indicates the best connection.
• Amber indicates a good connection.
• Red indicates a poor connection.
An LED that is off indicates no WiFi connection.
