Configuring the Switch
ProSAFE® Web Managed switches are Plug-and-Play, so they can be used without
any configuration. You can also configure and manage additional advanced features
of the switch either by using your computer’s web browser or by installing the
ProSAFE Plus Configuration Utility on your Windows-based computer.
Web Browser Access
You can configure a switch when it is connected only to your computer
(o-network), or connected to your computer and your network (on-network).
¾ To use your web browser to configure your switch:
1. If you are configuring the switch o-network, record your computer’s TCP/IP
configuration settings, and then configure the computer with a static IP address
of 192.168.0.210 and with 255.255.255.0 as the subnet mask.
Note: If you are unsure how to do this, visit netgear.com/support and
search for Static IP address on computer.
2. Plug the switch into a power outlet and connect your computer to the switch
using an Ethernet cable.
3. If you are configuring the switch on-network, connect the switch to your
network with another Ethernet cable.
4. Open a web browser and enter the IP address of the switch.
If the switch is o-network or connected to a network with no DHCP server,
use its default IP address, http://192.168.0.239. If the switch is connected
to a network with a DHCP server, use the IP address that the DHCP server
assigned to the switch. If you are unsure how to determine the IP address of
the switch, you can use the ProSAFE Plus Configuration Utility.
5. Enter the password.
The default password is password.
6. Click the Login button.
You can now configure additional options for the switch in the web browser
interface.
7. When you finish configuring an o-network switch, return your computer to
its original TCP/IP settings and connect the switch to your network using an
Ethernet cable.
ProSAFE Plus Configuration Utility Access
The ProSAFE Plus Configuration Utility runs on Windows-based computers. The
utility is on the resource CD that came with the switch. You can also visit
netgear.com/support/product/PCU to download the utility.
¾ To install the utility from the resource CD:
1. Insert the resource CD into a computer that is connected to the switch.
2. Click the Install ProSAFE Plus Utility link and follow the prompts to install
the program.
The utility is installed in the program directory of your computer and a
ProSAFE Plus Utility icon is placed on your desktop.
¾ To configure the switch:
1. Double-click the ProSAFE Plus Utility icon.
The configuration home page displays a list of Web Managed switches that it
discovers on the local network.
2. Select the switch that you want to configure from the list.
3. When prompted, enter the password.
The default password is password.
4. Use the utility to configure the switch settings.
For a description of Web Managed switch features, see the ProSAFE Plus
Configuration Utility User Guide. You can access the user guide through links on
the Help tab of the utility and from the resource CD.
Specifications
Specification Description
Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or 1000BASE-T
Network cable Category 5e (Cat 5e) or better Ethernet cable
Ethernet ports 8
Power consumption 5.8W maximum (no PoE)
148W maximum with PoE
PoE+ (802.3at) ports 8
Total PoE power budget
(across all ports)
30W maximum per PoE port, up to 124W total PoE power.
For more information, see PoE Specifications.
Power 100–240 VAC 50/60Hz, 3A maximum
Weight 3.53 lb (1.6 kg)
Dimensions (W x D x H) 15 in. x 3.9 in. x 1.7 in. (380 mm x 100 mm x 43.2 mm)
Operating temperature 32–122°F (0–50°C )
Operating humidity 0%–90% relative humidity, noncondensing
Support
Thank you for purchasing this NETGEAR product. You can visit
www.netgear.com/support to register your product, get help, access the latest
downloads and user manuals, and join our community. We recommend that you
use only ocial NETGEAR support resources.
For the current EU Declaration of Conformity, visit
http://kb.netgear.com/app/answers/detail/a_id/11621.
For regulatory compliance information, visit
http://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
