To mount the switch to a wall stud or to a solid surface:
1.
Peel the plastic cover off the adhesive squares on the rear of the bracket.
2.
Place the bracket on the wall or surface where you want to mount the switch.
3.
Mark the wall or the surface where the two mounting holes are and the drill holes.
4.
Attach the bracket to the wall or surface using the screws provided in the wall mount
screw kit.
5. Tighten the screws to secure the bracket.
6.
Line up the back of the switch (see the left figure) or the bottom of the switch (see
the right figure) with the bracket.
Hardware Installation Guide30Installation
8-Port and 16-Port Gigabit Ethernet (PoE+) Smart Managed Plus Click Switch
