3. LAN Gigabit Ethernet ports 1–3. LAN ports 1 and 2 support link aggregation.
4. WAN Gigabit Ethernet port (with a yellow label). Use this port for your Internet
connection.
5. DC Power connector
6. Reset button
7. Power LED
Orbi Pro WiFi 6 AX5400 satellite model SXS50 hardware
Figure 2. Orbi Pro WiFi 6 AX5400 satellite model SXS50, front and back views
1. Bar LED
2. Sync button (also used for WPS connection)
3. LAN Gigabit Ethernet ports 1–4. LAN ports 1 and 2 support link aggregation.
4. DC Power connector
5. Reset button
6. Power LED
User Manual12Overview and Setup
Orbi Pro WiFi 6 AX5400 Router Model SXR50 and Orbi Pro WiFi 6 AX5400 Satellite Model SXS50
