NETGEAR R8000 Installation

2
Install Your Router
Make sure that your Internet service is active before you install
your router.
¾ To install your router:
1. Extend the antennas.
Position the antennas for the best WiFi performance.
NETGEAR recommends that you position all of the antennas
vertically as shown.
2. Prepare your modem.
a. Unplug your modem’s power.
b. If the modem has a battery backup, remove its batteries.
c. If your modem was already connected to another router,
disconnect the cable between your modem and that router.
Make sure that your modem is turned o and is cabled only to
the wall jack for your Internet service.
Internet
Modem
DSL or
cable

NETGEAR R8000 Specifications

General

Model	R8000
WiFi Technology	802.11ac
WiFi Band	Tri-Band
Antenna	6 external antennas
RAM	256 MB
Flash Memory	128 MB
WiFi Speed	Up to 3200 Mbps
Processor	1GHz dual-core
Ethernet Ports	5 (1 WAN & 4 LAN) Gigabit Ethernet ports
USB Ports	1 x USB 3.0 + 1 x USB 2.0
Security	WEP, WPA, WPA2
