February 2018
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo
are trademarks of NETGEAR, Inc. Any non‑NETGEAR
trademarks are used for reference purposes only.
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
NETGEAR INTL LTD
Building 3, University Technology Centre
Curraheen Road, Cork, Ireland
Configure the Access Point
¾ Choose one of the following methods to configure the access point:
• Method 1: Use the NETGEAR Insight app. On your iOS or
Android mobile device, go to the app store. Search for NETGEAR
Insight, and download the app.
Open the NETGEAR Insight app and log in to your existing NETGEAR
account or create a new account to log in with. Then, follow the
prompts in the NETGEAR Insight app to discover and register the
access point on the network so that you can configure and manage
the access point. For more information on the NETGEAR Insight app,
see the NETGEAR knowledge base articles at netgear.com/support.
• Method 2: Log in over WiFi. From your computer or mobile
device, connect over WiFi to the access point’s default SSID. The
default SSID is on the
access point label on the
bottom of the access point
and is shown in the format
NETGEARxxxxxx-SETUP.
The default password is
sharedsecret.
Open a web browser. In
the address bar, enter
www.routerlogin.net
(or www.aplogin.net). The Day Zero Easy Setup page displays so
that you can configure the basic settings, including the country of
operation. Aer you save these basic settings, the Day Zero Easy
Setup page no longer displays when you log in.
• Method 3: Log in over Ethernet. Open a web browser from a
computer that is connected to the same Ethernet subnet as the
access point or to the access point’s LAN port directly through an
Problem Cause Possible Solution
No LEDs are lit on
the AP.
The AP is not
receiving power.
•Make sure that the AP is securely connected to a PoE switch.
•Make sure that the PoE switch is connected to a power source.
The Power LED
alternates green
and amber.
The AP is receiving
insucient PoE
power.
•Make sure that PoE switch is not overloaded.
•Connect to a power source such as a 12V 2.5 A power adapter.
The WAN or LAN
LEDs are o.
A hardware
connection problem
exists.
•Make sure that the cable connectors are securely plugged into the
AP and the switch.
• Make sure that the switch is turned on.
The WLAN LEDs
are o.
The WiFi
connection does
not work.
•Make sure that the PoE switch is providing sucient power to the
AP.
•Verify that the radio or radios are turned on.
•If the WLAN LEDs remain o, contact NETGEAR.
You cannot
connect to the AP
from a browser.
Multiple possible
causes.
•Make sure that your computer is using an IP address in the same
subnet as the AP. The AP default IP address is 192.168.0.100, and
the default subnet mask is 255.255.255.0.
•Quit the browser, clear the cache, delete the cookies, and launch
the browser again.
Support
Thank you for purchasing this NETGEAR product. You can visit
www.netgear.com/support to register your product, get help, access the latest
downloads and user manuals, and join our community. We recommend that you
use only ocial NETGEAR support resources.
Si ce produit est vendu au Canada, vous pouvez accéder à ce document en
français canadien à http://downloadcenter.netgear.com/other/.
(If this product is sold in Canada, you can access this document in Canadian-
French at http://downloadcenter.netgear.com/other/.)
For more information about the installation and configuration options, visit
www.netgear.com/support to access the user manual.
For the current EU Declaration of Conformity, visit
http://support.netgear.com/app/answers/detail/a_id/11621/.
For regulatory compliance information, visit
http://www.netgear.com/about/regulatory/.
See the regulatory compliance document before providing power to the access
point.
Ethernet cable.
In the address bar, enter the IP address of the access point.
Note: If the access point is connected to a network that includes a DHCP
server (or router that functions as a DHCP server), determine the IP address
by using an IP network scanner. Otherwise, the default IP address of the
access point is 192.168.0.100. If you use an Ethernet cable from your
computer to the access point’s LAN port and the access point functions with
its default IP address, make sure that the IP address of your computer is in the
192.168.0.x subnet.
The Day Zero Easy Setup page displays so that you can configure
the basic settings, including the country of operation. Aer you save
these basic settings, the Day Zero Easy Setup page no longer displays
when you log in.
Note: Make sure the country is set to the location where the device is operating. The
customer is responsible for complying within the local, regional, and national regula-
tions set for channels, power levels, and frequency ranges.
Deploy the Access Point
The best location for the access point is elevated, such as mounted on a wall
or ceiling, at the center of the WiFi coverage area, and within line of sight of
all mobile devices.
For information about mounting the access point, see the NETGEAR Insight
Managed Smart Cloud Wireless Access Point (WAC510) Ceiling and Wall
Installation Guide, which you can download from downloadcenter.netgear.com/.
¾ To deploy the access point:
1. Disconnect the access point and position it where you will deploy it.
2. Reconnect the access point. See Set Up the Access Point.
3. Using a WiFi device, verify connectivity by connecting to the access point
and using a browser to connect to the Internet.
Troubleshooting Tips
The following table provides some tips for correcting simple problems that
you might encounter. For more troubleshooting information, see the
NETGEAR
Insight Managed Smart Cloud Wireless Access Point (WAC510) User Manual.
