Getting to Know Your Wireless Router 5
Back Panel
The rear panel of the WNDR3700v3 router contains the items in the list that follows the figure.
The back of the N600 wireless gigabit router includes:
1. A USB 2.0 port (backward compatible to USB 1.0/1.1) for attaching a USB storage device.
2. Four local (LAN) 10/100/1000 Mbps Ethernet ports for connecting the router to local
computers.
3. An Internet (WAN) 10/100/1000 Mbps Ethernet port for connecting the router to a cable or
DSL modem.
4. An AC power adapter outlet.
5. A Power On/Off button.
Figure 3
1
2
3
4
5
