NETGEAR WNR2000 User Manual

Manually Installing Your Router 13
5. Locate the Ethernet cable that came with your NETGEAR product. Securely insert one end of
the Ethernet cable into your modem (C) and the other end into the Internet port of the wireless
router (D). (The cable and the Internet port label are color coded.)
6. Locate the cable (A) that is still attached to your computer (see step 4). Securely insert that
cable into a port on the router, such as port 4 (E), as shown in Figure 9.
7. Connect any additional wired PCs to your router by inserting an Ethernet cable from a PC into
one of the three remaining LAN ports.
Figure 8
Figure 9
,QWHUQHW
,QWHUQHW




C
D
1
2
3
4
Internet
A
E

NETGEAR WNR2000 Specifications

General

Rack mounting	No
xDSL connection	Yes
Dimensions (WxDxH)	177.5 x 130 x 35 mm
Maximum data transfer rate	0 Gbit/s
WLAN data transfer rates supported	300 Mbit/s
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Product color	Black
Wi-Fi standards	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	4
Web-based management	-
Security algorithms	WPA, WPA2-PSK

Weight and Dimensions

Depth	132 mm
Width	48 mm
Height	108.7 mm
Weight	163 g
