5
LED Descriptions
The LEDS indicate the status of your Powerline adapters.
• When you plug in the adapter, the Power LED lights and
turns green.
If the Ethernet port is inactive for more than 10 minutes, the
adapter enters power saving mode and the Power LED turns
amber. Power saving mode is disabled by default.
• The Ethernet LED lights and turns green when you connect
a powered-on Ethernet device to the adapter’s Ethernet port. If
the Ethernet LED is off, there is no Ethernet connection.
• The Powerline LED lights when the adapter detects at least one
other compatible Powerline device.
The Pick A Plug features lets you pick the electrical outlet with the
fastest link rate:
• Green: Link rate > 80 Mbps (fast)
• Amber: Link rate > 50 and < 80 Mbps (medium)
• Red: Link rate < 50 Mbps (slow)
