NETGEAR XE102

XE102 Wall-Plugged Ethernet Bridge User Guide
2
v1.0, June 2007
Front Panel Status Lights
The front panel of the XE102 contains status lights. You can use them to verify connections. The
table below describes the lights on the front panel.
Table 1. Front Panel Status Light Descriptions
Front Panel
Status
Light
Description
Power • On green solid. Power is supplied to the Ethernet bridge.
• Off. Power is not supplied to the Ethernet bridge.
HomePlug • On. The HomePlug port has detected another PowerLine device on
the PowerLine network.
• Blink. Data is being transmitted or received on the PowerLine
network.
• Off. No other PowerLine devices detected on the PowerLine network.
Ethernet • On green solid. The Ethernet port is linked but there is no activity.
• Blink. Data is being transmitted or received on the Ethernet port.
• Off. No link is detected.
