Setup
The main configuration menu displays a screen like the following:
/------------------------/
/ Setup /
/------------------------/
IP config......:<--
Time setting...:
UPS config.....:
Services 1.....:
Services 2.....:
Security.......:
Save and load..:
Press [Esc] to quit
SysVer. S15-1 - AppVer. 01.04.000
From this main menu it is possible to access the various submenus, the function of each of which
is shown in the table below.
Menu Function
IP config To configure the network parameters
Time setting To configure the internal clock
UPS config To configure the type of UPS connected
Services 1
To activate and/or deactivate device services
Services 2
Security To configure the password and access to the network
Save and load To save a configuration: this action will reboot automatically the device.
The screen also displays some messages describing the kind of configuration data displayed and
the status of the UPS. The meaning of these messages is described below.
• Data from flash: means that the configuration has been loaded from the flash memory
• Default data: means that the configuration has been reset to the default values
- 16 -
