Pressing the ENTER key corresponding to the “Firewall” command displays a screen like the one
shown below.
/------------------------/
/ Firewall /
/------------------------/
Access IP 1....:*.*.*.*
Access IP 2....:0.0.0.0
Access IP 3....:0.0.0.0
Access IP 4....:0.0.0.0
Access IP 5....:0.0.0.0
Access IP 6....:0.0.0.0
Access IP 7....:0.0.0.0
With this menu the IP addresses or hostnames of the devices enabled for communication with
NetMan 204 can be configured. The character “*” can be used for one or more fields of the IP
address to indicate that all values between 0 and 255 are accepted in that field. The following table
provides some possible configuration examples.
IP Access Description
*.*.*.*
All the devices present on the network are enabled to communicate with
NetMan 204 (default configuration)
The devices with addresses between 10.1.10.0 and 10.1.10.255 are
enabled to communicate with NetMan 204
