NetMan 204 - Page 44

OBJECT DESCRIPTION UNIT
Analogue Input 0
Input voltage line 1
V
Analogue Input 1
Input voltage line 2
V
Analogue Input 2
Input voltage line 3
V
Analogue Input 3
Input current line 1
A
Analogue Input 4
Input current line 2
A
Analogue Input 5
Input current line 3
A
Analogue Input 6
Input frequency
Hz
Analogue Input 7
Bypass voltage line 1
V
Analogue Input 8
Bypass voltage line 2
V
Analogue Input 9
Bypass voltage line 3
V
Analogue Input 10
Bypass frequency
Hz
Analogue Input 11
Output voltage line 1
V
Analogue Input 12
Output voltage line 2
V
Analogue Input 13
Output voltage line 3
V
Analogue Input 14
Output current line 1
A
Analogue Input 15
Output current line 2
A
Analogue Input 16
Output current line 3
A
Analogue Input 17
Output peak current line 1
A
Analogue Input 18
Output peak current line 2
A
Analogue Input 19
Output peak current line 3
A
Analogue Input 20
Output power line 1
W
Analogue Input 21
Output power line 2
W
Analogue Input 22
Output power line 3
W
Analogue Input 23
Output frequency
Hz
Analogue Input 24
Output load line 1
%
Analogue Input 25
Output load line 2
%
Analogue Input 26
Output load line 3
%
Analogue Input 27
Battery voltage
V
Analogue Input 28
Battery current
A
Analogue Input 29
Battery capacity
%
Analogue Input 30
UPS temperature
°C
Analogue Input 31
Autonomy
min
Analogue Input 32
Nominal power
VA
Binary Input 0
Mains status
Present / Not present
Binary Input 1
Bypass status
Active / Not active
Binary Input 2
Battery status
Working / Not working
Binary Input 3
Battery level
Low / Not low
Binary Input 4
UPS locked
Locked / Not locked
Binary Input 5
UPS fail
Fail / Not fail
Binary Input 6
Load
Overload / Normal
Binary Input 7
Temperature
Overtemperature / Normal
Binary Input 8
Bypass bad
Bad / Not bad
Binary Input 9
Replace battery
Replace / Not replace
Binary Input 10
Shutdown
Active / Not active
Binary Input 11
Shutdown imminent
Imminent / Not imminent
Binary Input 12
Communication status
Lost / OK
- 44 -
