3
Assembly
Assembly and operation
Charging warning
A: Floater
B: Upper cover
B-1: Jet head
C: Filter
D: Bottom base
E: Charger
A
B
B-1
E
C
D
Switch
Charging port
Bottom cover body assembly bottom
There is a rotation jet head at the upper cover, the water is
passing from bottom to the jet head to make the robot
moving. While facing obstacle, the jet head turns around 180
degrees, the robot rounds the obstacle and moving by another
line. The rubbish is collected and installed by the bottom filter
cabine.
Use only the original external adapter and the charging cable
provided.
Make sure the robot and charger ports are clean and dry
before installation.
Power up the robot before using it for the first time (about 4-5
hours)
Note:
Once the robot starts charging, the
indicator light on the external adapter
will turn red. When the robot is fully
charged, the indicator light will turn
green.
