3.6 Top Screen Assembly
Remove the protective film from the top screen before
installing it into the fireplace. The pegs at the front of the
screen rest on brackets as shown below. When installing be
aware of your fingers and avoid pinch points.
Connect the top screen:
1. HDMI
2. Power
3. Backlight
Replace the rear and top panels with 8 (M5 x 10) screws.
The fireplace in now ready to be installed into your wall.
