SPECIFICATIONS
I/O
Input unbalanced ¼” TS
Nominal input level -10 dBV, instrument level
Input impedance 1 MΩ
Output unbalanced ¼” TS
Output impedance 1 kΩ
Output level 0 dB @ 50% level
MIDI IN/OUT compliant with MIDI Specification CA-033
ELECTRICAL
Sample rate 96 kHz
Minimum latency 0.315 ms
Bypass relay, true bypass
POWER
Input 9 - 12 V DC
Current 70 mA
Connector center-negative, 5.5 mm OD x 2.1 mm ID
Recommended adapter 9 V DC, 100 mA or greater pedal power supply
PHYSICAL
Dimensions 4.6” W, 2.8” L, 1.9” H / 116 mm W, 68 mm L, 47 mm H
Weight 0.564 lbs / 256 g
