Neuton CE5.4 User Manual

10 www.neutonpower.com
Lever Position Cut Height
1 1.2" (30 mm)
2 1.5" (38 mm)
3 1.9" (47 mm)
4 2.2" (56 mm)
5 2.6" (65 mm)
6 3.0" (75 mm)
Side Discharge Chute (sold separately)
The Side Discharge Chute (Figure 15) allows for proper discharge of the grass, which prevents clogging.
1. Raise the hinged Discharge Guard on the back of the Mower (Figure 12 on the previous page).
2. Position the Top Front Groove (Figure 16) of the Chute over the Support Rod (Figure 12) and lower the Chute into place
(Figure 15).
3. Lower the hinged Discharge Guard.
Step 8: Adjust the Cutting Height.
Using the Cutting Height Lever (Figure 17), adjust the Cutting Height so that you cut off only one (1) to two (2) inches of grass
at a time.
1. Make sure all four (4) Wheels are level.
2. Pull the Lever out of its present notched position and rotate the
Lever up or down to the desired level. When you reach the
desired level, simply release the Lever into the notch.
NOTE: Each position adjusts the Mower’s Blade level to a different
Cutting Height. Rotating the Cutting Height Lever towards
Position 6 (down) cuts less grass (which leaves your grass
longer); rotating the Lever towards Position 1 (up) cuts more
grass (leaving your grass shorter).
The following table lists the final cut grass heights.
Figure 15 Figure 16
Discharge Guard
Side Discharge Chute
Top Front Groove Side Discharge Chute
Figure 1
7
Cutting
Height
Leve
r
