Neve 1073 - Dimensions and Weight; Stand-alone Module Dimensions; Rack Mounting Dimensions

Mains Voltage Adjustment
1.) Switch off unit.
2.) Remove fuse.
3.) Turn inner barrel with screwdriver or coin until correct voltage figure is under the white
arrow on the housing.
4.) Replace fuse.
Di men sions
Stand-alone Mod ules Width
mm (inches)
Height
mm (inches)
Depth
mm (inches)
Ap prox.
Weight
kg (lbs)
1073 Module 45 (1.8) 222 (8.75) 254 (10) 2.5 (5.5)
1084 Module 45 (1.8) 222 (8.75) 254 (10) 2.5 (5.5)
19" Rack Mount ing U Depth
mm (inches)
Height
mm (inches)
Ap prox. Weight
kg (lbs)
2 Mod ule Ver sion 3 405 (16) 133 (5.25) 11 (24.2) *
8 Mod ule Ver sion 5 405 (16) 222 (8.75) 30 (66) *
* Fully populated rack
User Guide Is sue 5.1 Page 3
1073 & 1084 User Man ual Di men sions
