3
-
OPERA
TING
INSTRUCTIONS
Installing
the
bucket
level
indicator
1.
Install
the
bucket
level
indicator
rod
(1)
through
the
hole
in
the
inner
right
side
bucket
plate
(2)
.
86060304
1
2.
Install
the
at
washer
(1)
,
and
cotter
pin
(2)
onto
the
rod
end.
86060305
2
3.
Slide
the
indicator
bracket
(1)
over
the
top
end
of
the
rod
(2)
and
position
at
the
bend
(3)
in
the
rod.
4.
Make
sure
that
the
bucket
is
resting
on
the
ground,
and
is
in
a
level
position.
86060306
3
3-10
41
43
