SECTION 1 – GENERAL INFORMATION AND SAFETY
1–41
Extra safety latch
For some countries, a extra safety latch is installed
onto the right-hand side of the header lift cylinder.
40
Wheel chock
For some countries the metal wedges (1) are stored
at the right-hand side of the straw elevator.
41
When the machine is parked on a nonlevel surface,
the wedge (1) has to be placed at the lowest side,
against the traction wheel.
NOTE: Never place the wedges against the steering
wheels.
42
Buzzer (if installed)
On the top of the straw hood a buzzer is installed to
inform people that there will follow an action with the
combine. When the ignition key is put in “contact”
position the buzzer sounds once. When the combine
is placed in reverse, the buzzer sounds intermittently.
NOTE: The revolving flash lights (if installed) will also
flash for 2.5 seconds when the ignition key is put in
“contact” position. 43
