New Holland TH Telehandler - Shuttle Modes

Shuttle Modes
Shuttling mode 1 Shuttling mode 2 Shuttling mode 3
Comfort
(speed/ratio
logic)
Silage / Heavy Duty Memory
F1 ↔ R1 F1 ↔ R1 F1 ↔ R1
F2 → R2, R2 → F3 F2 ↔ R2 F2 ↔ R2
F3 ↔ R2 F3 → R2, R2 → F2 F3 ↔ R2
F4 → R3, R3 → F5 F4 → R2, R2 → F2 F4 ↔ R3
F5 ↔ R3 F5 ↔ R3 F5 ↔ R3
F6 → R3, R3 → F5 F6 → R3, R3 → F5 F6 ↔ R3
To change shuttle modes follow this quick step by step guide.
Press and hold enter button until
“SETUP MENU” is displayed
Use UP/DOWN button to
navigate to the transmission
symbol shown in display
Toggle between modes 1,2 and
3 and select any one needed by
pressing enter.
5
See below table for shuttle mode options
