7. Carefully attach the pedals to the crank arms and start tightening them by hand:
• The Right pedal should be tightened in a clockwise direction.
• The Left pedal should be tightened in an anticlockwise direction.
8. The thread on the pedals should be found easily. If not, check you have the
correct pedal for that side of the bike, remove and realign it, then try again.
Once the pedal is partly screwed into the crank, use the 15mm spanner to
tighten it fully. Excessive force may damage the pedal and/or crank arm.
6. The pedals look similar but one is intended for the right crank and one for the
left crank. Each pedal is marked with either an R for right and L for left. The right
and left side of the bike are as seen from the perspective of a seated rider.
