1. Remove the four plastic inserts located around the bottom of the box.
Then, with two people, lift the top box off and set it down next to the bike.
If your bike has a front light, do not use it to lift the bike. It is not designed to hold the
weight of the bike.
2. Remove the accessories box from the tower. In this box you will nd:
3. Slide out the tower, so you can carefully roll your 345-E out from the box. Use the
bike’s kickstand to lean the bike on while you complete the rest of the assembly.
1 x 6mm Allen key 2 x pedals
1 x 15mm pedal spanner 1 x battery charger
1 x user manual 1 x bell
2 x battery keys
08
