REPLACEMENT PARTS
List Part Numbers – Newmac Status
Model NS220 Wood Heater
KEY NO.
PART NO. DESCRIPTION
1 2140050 Draft Control Knob
2 2210255 High/Low Label
3 2160006 Cotter Pin 1/16 x ¾”
4 2220006 7/8” x 3/8” Diameter Spring
5 3090359 Thermostat Stop
6 3090358 Thermostat Standoff
7 2220007 BI Metal Thermostat Spring
8 3070015 Damper Chain
9 4110534 Draft Door Painted
10 4110560 Cast Air Inlet
11 3090354 Smoke Pipe Baffle
12 4110535 Cast Pipe Connector Painted
13 4110537 Louvre Panel Painted
14 3090360 Scandinavian Baffle
15 4060291 Top Rear Brick Loc Assly
16 4060290 Rear Brick Rack Assly
17 4110538 Main Body Assly Painted
18 2030011 Split Brick
19 4110532 Draft Box Painted
20 4160125 Firedoor C/W Rope Gasket Glued
21 4110539 Door Handle
22 2160011 Door Pins (7/32 x 3.25”)
23 3030010
Front Liner
24 3030010 Front Liner
25 4110536 Base Panel Assly Painted
26
3120163
3120160
Brick Spacer
Bottom Brick Rack
27
4060293
4060292
Right Top Brick Rack
Left Top Brick Rack
28 4110531 Door Catch Painted
29 3040234 Base Retainers (In Parts Bag 4100150)
30 2080080 Door Gasket 42” Rope
31 4100150 Parts Bag
32 2210254 Instruction Manual
33 4110530 Draft Screen Painted
34 4110561 Wooden Handles, Stained Brown (In Parts Bag 4100150)
35 4110561 Wooden Handles, Stained brown (In Parts Bag 4100150)
36 4060285 Inner Draft Chute Assly
**NOTE: Some parts available as complete assemblies only
