REPLACEMENT PARTS
List Part Numbers – Newmac Classic
Model NC100 Wood Heater
KEY NO.
PART NO. DESCRIPTION
1 2140050 Draft Control Knob
2 2210255 High/Low Label
3 2160006 Cotter Pin 1/16 x ¾”
4 2220006 7/8” x 3/8” Diameter Spring
5 3090359 Thermostat Stop
6 3090358 Thermostat Standoff
7 3090359 Thermostat Stop
8 2220007 Bi Metal Thermostat Spring
9 4110535 Cast Pipe Connector Painted
10 2220013 Hinges 1 ½” x 1 ½”
11 4110541 Top Louvre Panel (Painted)
12 2160011 7/32 x 3 ¼” Steel Door Pins
13 4110561 Wooden Knobs Stained Brown
14 4110542 Rear Panel Assembly (Painted)
15 4110545 Casing Door (Painted)
16 4110561 Wooden Knobs Stained Brown
17 2220016 Roller Catch
18 3120168 Rear Brick Spacer
19 2030011 Split Brick
20 4110544 Casing End (Painted)
21 4110547 Screen Assembly (Painted)
22 2210257 Classic Label
23 4110543 Front Bottom Louvre Panel (Painted)
24 4110551 Draft Door
25 3070017 Top Damper Chain
26 4110560 Cast Air Inlet
27 2170022 Cast Iron Grates
28 4060314 Top Brick Rack
29 4060315 Bottom Brick Rack
30 3030014 Front Liners
31 2160011 7/32 x 3 ¼ “ Steel Door Pins
32 4160126 Firedoor c/w Rope Gasket Glued
33 2080080 Door Gasket 42” Rope
34 4160127 Ashdoor c/w Rope Gasket Glued
35 2080080 Ashdoor Gasket 28.8” Rope
36 4010315 Ashpan
37 4110539 Door Handle
38 4110561 Wooden Handles, Stained Brown
39 4110531 Door Catch Painted (Only 1 Replaceable)
40 N/A N/A
41 4110546 Casing Door Frame End (Painted)
42 4110549 Firebox Assembly (Painted)
NOTE: Some parts available as complete assemblies only.
