10.Activatepainttrigger.Themotorshouldrotatetherollerpumpinaclockwisedirectionas
youfacethemachine.Pleasecallthefactoryifthemotorisnotworkingatthispoint.NOTE:A
brandnewbatterymayrequirechargingovernight.

11.Carefullyslidebatterycoverbackontopumpsupport(makingsurepainttriggerwiresdo
notgetsnagged)andsecurewiththefourboltsandwashersyoupreviouslyremoved.

12.Removetherollercarrierfromthepolybag.Removetherubberbandsecuringmandreland
removethemandrelandmandreltubefromcarrier.Discardtherubberbandandtheset
mandrelaside.

13.Attachtherollercarriertothesupportbarbyremovingtheboltandwasher.Lightlygrease
theboltandmounttherollercarrierwithonewasheronoutsideofthecarrierandbolt.(Bolt
shouldbetightenoughtoremoveanyplay,butlooseenoughtoallowtherollercarriertopivot
upanddownfreelywithbothwheelssittingflatonthepavementwheninthedownposition.)

14.Pullliftingleverbackward(Operatingposition).Attachtheliftingrodtotherollercarrierby
removingcotterhairpin,lightlygreasetherodendandslidetherodendintohole.Re‐installthe
cotterhairpin.(Movetheliftingleverforwardorbacktoalignrod&hole)Liftingleverwillnow
liftthecarrierupoffofthegroundwhentheleverispushedforward.

15.Installthehoseguide(‘L’shapedbar)intheholeinthefrontrightcorneroftheframesoit
isparalleltothefrontofthemachine.
