About this Manual
User Manual forAZ710 Up Converter
version 1.2
ix
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
Options
AZ710 Upconverter
Default Configuration
Ordering n°
IF 70MHz or 140MHz to L-band Upconverter, SNMP
AZ710
Upconverter output: L-band (950 - 1750MHz)
10MHz reference In/Out 1ppm
Configuration Options
Category
Max. 1
option per
category
Output interface
L-band (950 - 1750 MHz)
Default
L-band + 10MHz for BUC
FA-02
L-band + 10MHz + 24Vdc for BUC
FA-03
L+C-band (5,85 - 6,65 GHz)
FA-04
L+Ku-band ( 12,75 - 13,25 GHz )
FA-05
L+Ku-band ( 13,75 - 14,50 GHz )
FA-06
L+DBS-band (17,30-18,10 GHz)
FA-07
L+DBS-band (17,60-18,40 GHz)
FA-08
10MHz reference In/Out Internal reference : 1ppm
Default
Internal reference : 0,01 ppm
GR-02
Feedback
Newtec encourages your comments concerning this document. We are committed
to providing documentation that meets your needs.
Please send any comments by contacting us at
documentation@newtec.eu.
Please include document and any comment, error found or suggestion for
improvement you have regarding this document.
