4.3.6 Message format
The general syntax for all messages is:
• Start byte
• Address byte
• Message header
• Message data
• End of text byte
• Checksum byte
4.4 SNMP
The Newtec MIB allows full monitor and control over the complete device using any
SNMP browser (HP-OpenView, NetworkView). Newtec supports the basic standard
MIB (monitor and control of IP interface, versions of the software …) and above
that we have a full proprietary MIB, which contains all the OIDs needed to control
the device.
We support traps. These form a mechanism to trigger the NMS when a change in
the device has occurred. After receiving the trap the NMS still has to poll the device
to find out the details of the change.
The SNMP details can be found in the AZ710 Reference Manual.
