Connections Set Up | Front Panel
6. NDI
®
Output Connector
• Connect network cable from
the Spark Plus
™
I/O 4K to NDI
®
Source Connector (5) on unit
7. HDMI Input Connector
• Connect HDMI cable from video
source to the Spark Plus
™
I/O 4K
8. Microphone Connector
• Connect microphone input
9. Headphone Connector
• Connect headphones for audio
monitoring
10. Audio L-R In Connectors
• Connect line level audio source
11. Audio L-R Out Connectors
• Connect line level audio output
12. Power Switch
• Press to turn on power to the unit
Front
Spark Plus
™
I/O 4K
We really want to see what you’re up to…
share your videos, pictures (preferably with your
shades on) and cool stories on our Facebook
page, Instagram, LinkedIn, Twitter, or whatever
social media site you hangout on. There’s a
NewTek account wherever you go.
