Nexo GEOM1012 - Page 5

GEOM10 RIGGING Page 5/17
Disassembly
Front (stacked or unflown)
On both side, pull AutoRig
TM
and holding the knob. AutoRig
TM
remains in the open position.
Back
Remove the quick release pin 0820AV. Unlock the GEOM10 link bar by pulling the latch.
SAFETY: You can replace one of the four screws with an eyebolt (M8), and use a sling (apply thread
lock on the eyebolt).
