PARKER BED (WARDROBE)
136660
14
565825-2019-V1.
Assembly instructions
Produced in China for Next Retail Ltd.
WHEN LOOSENING THE CAM
TURN THE CAM IN A COUNTERCLOCKWISE DIRECTION
UNTIL THE ARROW POINTS IN THE POSITION SHOWN
IN THE DIAGRAMS BELOW
TURN
UNLOCKED
MAXIMUM
LOCK
TO UNLOCK
TOP
WALL
STRAP
SCREW
WASHER
