NextBase SDV485-B User Manual

LEFTSIDE
Volumecontrol
Useittoadjustthevolumeofthe
speakerortheearphone.
1.
2.
4.
5.
6.
Videoin/outjack
Inputoroutputvideosignalsto
connecteddevicebysettingAV
IN/OUTmodevalue.
TheincludedAVcableis
connectedfromhere.
PARTSANDCONTROLS
RIGHTSIDE
ENG14
MOBILEENTERTAINMENT
3 5
6 7
2 4
3.
Earphonejack
Forconnectingastereoearphone
oranamplifier.
DCOUT(DC12V500mA)
DCoutput.
Note:
ThisDCoutportcanconnectto
productsfromourcompanyonly.
Otherwiseitmightcausebad
performance.
Themaximumoutputcurrentis500mA.
Audioin/outandoptical
outputjack
Inputoroutputaudiosignals
toconnecteddevicebysetting
AVIN/OUTmodevalue.
Outputopticalaudiosignalsto
connecteddevice.
TheincludedAVcableoroptical
digitalcableisconnectedhere.
Poweron/off
DCIN(DC12V)
ConnecttheincludedAC/DC
adapterhere.
7.
