6
Feature Functionality
1. Power button
Press and hold to turn the tablet on or off.
Press to turn the display on or off.
2. Volume+/- buttons
Press to increase/decrease volume
3. Windows button
Press to open the Windows Start screen.
Press for quick access to the most recently used
app or most recently viewed screen.
4. Microphone
Records sounds.
Provides sound input while making calls using
web-based apps.
5. microSD card slot
Reads and writes files stored on a microSD card.
6. HDMI port
Connect HD television via optional HDMI cable, for
switching the display to wider screen.
7. Micro-USB port
Connect USB devices, via an optional USB
On-The-Go (OTG) dongle, for transferring data,
music, photos, videos, and so on.
8. DC-In socket
Connect the supplied power adapter for charging the
battery.
9. Audio port (3.5 mm)
Connect a headset, headphones, microphones, or
other audio equipment to listen to stereo sound,
record audio, or make calls.
10. Batter
-status light
Indicates the battery-charge status.
11. Front-facing camera
Capture a front view picture or record videos.
Use while making video calls.
12. Sustaining port
female
Fix and sustain the connection to external keyboard.
13. Pogo pin connecto
female
Connect external keyboard
14. Speake
Provides audio output.
15. Rear camera
Captures pictures or videos.
Note:
1. Both cameras do not support zoom, face tracking.
2.The Micro-USB port does not support connecting to a computer, or power sharing
to connected USB devices.
3. User can connect a keyboard and USB mouse to this tablet if necessary.
Basic Connections
Charging the tablet
The tablet has a built-in rechargeable battery. Charge the device when the battery
level is low.
1. Plug the power adapter into the DC-In socket.
2. Connect the power adapter to an electrical outlet and charge the tablet until the
