3. OPERATING INSTRUCTIONS
3.1 MEASURING VOLTAGE
1. Connect the black test to the COM jack and the red test lead to the V/Ω jack.
2. Set the function switch at V or V ~ range to be used and connect test leads across the source
or load under measurement.
3. Read LCD display. The polarity of red connection will be indicated when making a DC
measurement.
3.2 MEASURING CURRENT
1. Connect the black test lead to the COM jack and the red test lead to the mA jack for a maximum
of 500mA. For a maximum of 10A, move the red lead to the A jack.
2. Set the function switch at µA, mA or A range to be used and push / ~ button to select DCA of
ACA measuring mode.
-11-
