Connecting the NI 9269
The NI 9269 has four 2-terminal detachable screw-terminal
connectors that provide connections for 4 analog output channels.
Figure 2. NI 9269 Terminal Assignments
AO0+
AO0–
AO1+
AO1–
AO2+
AO2–
AO3+
AO3–
0
1
0
1
0
1
0
1
