PROGRAM SETTINGS
Program setting of AXC 30 can be performed via the
start guide or directly in the menu system.
Start guide
The start guide appears at first start-up after the heat
pump installation, but can also be found in menu 7.7.
MENU SYSTEM
If you do not make all settings via the start guide or need
to change any of the settings, this can be done in the
menu system.
Menu 7.2.1 - Add/remove accessories
Here, you state which accessories are installed for the
compatible product.
To identify connected accessories automatically, select
"Search for accessories". It is also possible to select ac-
cessories manually from the list.
Menu 7.2.3 - Shunt-contr. add. heat(AXC)
Prioritised add. heat
Setting range: on/off
Setting range: 0 – 2000 DM
Minimum operating time
Setting range: 0 – 48 h
Lowest temperature
Setting range: 5 – 90 °C
Shunt amplification
Setting range: 0.1 –10.0
Shunt waiting time
Setting range: 10 – 300 s
Set when the addition is to start, the minimum run time
and the minimum temperature for external addition with
shunt here. External addition with shunt is for example
a wood/oil/gas/pellet boiler.
You can set shunt valve amplification and shunt valve
waiting time.
Selecting "Prioritised add. heat" uses the heat from the
external additional heat instead of the heat pump. The
shunt valve is regulated as long as heat is available,
otherwise the shunt valve is closed.
See the accessory installation instructions for function
description.
Menu 7.5.3 - Forced control
Here you can force control the various components in
the installation. The most important safety functions
remain active however.
NOTE
Forced control is only intended to be used for
troubleshooting purposes. Using the function
in any other way may cause damage to the
components in your climate system.
Menu 4.6 - Smart Energy Source
Smart Energy Source
Alternative: on/off
Control method
Alternatives: Price per kWh / CO2
If Smart Energy Source™ is activated AXC 30 prioritises
how / to what extent each docked energy source will
be used. Here you can select whether the system will
use the energy source that is cheapest at the time or
the one that is most carbon dioxide neutral at the time.
Caution
Your choices in this menu affect menu 4.7 -
Energy price.
Caution
Also see the Installer Manual for the main
product.
11AXC 30 S-series | GB
