The table displays the total phase current for the immer-
sion heater at start up. If an immersion heater has
already been started and is not used for its full capacity
the values in the table can be changed because the
control initially uses this immersion heater.
Switching to maximum electrical output
If more than the maximum output (7 kW) for the immer-
sion heater connected on delivery is needed, the heat
pump can be switched to maximum 9 kW.
Move the white cable from terminal block X7:23 to ter-
minal block X3:13 (the seal on the terminal block must
be broken) on the immersion heater card (AA1).
3x400V V (maximum electrical output, connected
upon delivery 7 kW)
Max phase
current
L3(A)
Max phase
current L2(A)
Max phase
current L1(A)
Max electric-
al addition
(kW)
–––0
4.3––1
–8.7–2
4.38.7–3
8.78.7–4
13.08.7–5
8.78.78.76
13.08.78.77
3x400V (maximum electrical output, switched to
9 kW)
Max phase
current
L3(A)
Max phase
current L2(A)
Max phase
current L1(A)
Max electric-
al addition
(kW)
–––0
–8.7–2
8.78.7–4
8.78.78.76
15.615.68.79
3x230V
Max phase
current
L3(A)
Max phase
current L2(A)
Max phase
current L1(A)
Max electric-
al addition
(kW)
–––0
–9.49.42
8.715.69.54
15.615.615.66
25.627.415.69
If the current sensors are connected, the heat pump
monitors the phase currents and allocates the electrical
steps automatically to the least loaded phase.
EMERGENCY MODE
When the heat pump is set to emergency mode (SF1
is set to ) only the most necessary functions are activ-
ated.
• The compressor is off and heating is managed by the
immersion heater.
• Hot water is not produced.
• The load monitor is not connected.
NOTE
The switch (SF1) must not be moved to "" or
" " until F1145 has been filled with water.
Components in the product can be damaged.
Power in emergency mode
The immersion heater’s output in emergency mode is
set with the dipswitch (S2) on the immersion heater
circuit board (AA1) according to the table below. Factory
setting is 6 kW.
3x400V (maximum electrical output, connected
upon delivery 7 kW)
654321kW
onoffoffoffoffoff1
offoffoffonoffoff2
onoffoffonoffoff3
offonoffonoffoff4
onoffoffonoffon5
offonoffonoffon6
ononoffonoffon7
3x400V (maximum electrical output, switched to
9 kW)
654321kW
offonoffoffoffoff2
offonoffonoffoff4
offonoffonoffon6
ononononoffon9
3x230V
654321kW
offoffonoffoffoff2
offoffonoffonoff4
offoffonoffonon6
offoffonononon9
25Chapter 5 | Electrical connectionsNIBE F1145
