INSTALLATION
Transmitters:
The transmitters are ready to use, each with their own code number set during construction. To see
if they are working properly simply press one of the keys and check that the red LED is flashing which
indicates transmission.
The transmitter has a device built into it that controls battery state: press one of the keys and if the
battery is fully charged, the LED will give an initial pulse followed immediately by the transmission
signal. If the battery is partly flat the
LED will give the first pulse and start
transmitting only after half a second.
In this case we advise you change the
battery as soon as possible.
On the other hand, if the battery is
completely flat the LED will flash at
half-second intervals without
transmitting and the battery must be
changed immediately.
- 32 -
VERY FLO1R FLO2R FLO4R
LED
KEY 1
KEY 2
KEY 3
KEY 4
LED
KEY 1
KEY 2
Fig. 1
