Connecting the relay outputs
1. Follow the warning and safety instructions and take the appropriate precautions.
2. If necessary, pull the red or yellow terminal block out of the socket.
3. Loosen the screws on the blue terminal block.
4. Insert up to 5 mm of stripped cable into the slot on the side of the terminal block and fasten.
5. Tighten the screw.
6. If necessary, insert the terminal block back into the red or yellow 3-pole socket.
→ The cables of the relay outputs are firmly attached to the terminal block with no exposed wires.
Connect the relay cable to the external device
1. Comply with the warning and safety instructions for the external device.
2. Follow the manufacturer’s instructions on wiring the outputs on the external device.
→ The relay outputs are connected to the signal outputs on the external device.
