LP21/LP22 Installation instructions en Sensors
Symbol
Description
Highlighted direction logic delivers false counts for this setting
Pulse signal travel direction A
Pulse signal travel direction B
Continuous signal
Loop free
Loop covered
Tab.24: Key to direction logic
You can find information on the detailed functions for different traffic situations in the following section.
9.8.1 “Single vehicle” direction logic
Fig.10: Single vehicle direction logic
