EN
10 – English
EC DECLARATION OF CONFORMITY
Note - The contents of this declaration correspond to declarations in the last revision of the official document deposited at the registered offices of Nice Spa available before this
manual was printed. The text herein has been re-edited for editorial purposes.
Number: 296/MC424 Revision: 0
The undersigned, Lauro Buoro, in the role of Managing Director, declares under his sole responsibility, that the product:
Manufacturer’s Name: NICE s.p.a.
Address: Via Pezza Alta 13, Z.I. Rustignè, 31046 Oderzo (TV) Italy
Type: Two 24 Vdc motor control unit
Models: MC424
Accessories: SMXI, SMXIS radio receiver
conform with the requirements of the following EC directives:
• 98/37/EC (89/392/EEC amended); DIRECTIVE 98/37/EC OF THE EUROPEAN PARLIAMENT AND COUNCIL of 22 June 1998 regarding the approxima-
tion of member state legislation relating to machinery.
As established in directive 98/37/EC, the above-mentioned product may not be started up unless the machine in which the product is incorporated has
been identified and declared as conforming to directive 98/37/EC.
The product also complies with the requirements of the following EC directives:
• 2006/95/EEC (ex directive 73/23/EEC); DIRECTIVE 2006/95/EEC OF THE EUROPEAN PARLIAMENT AND COUNCIL of 12 December 2006 regarding
the approximation of member state legislation relating to electrical material intended for use within specific voltage limits
According to the following harmonised standards: EN 60335-1:1994+A11:1995+A1:1996+A12:1996+A13:1998+A14:1998+A15:2000+A2:2000+
A16:2001
• 2004/108/EEC (ex directive 89/336/EEC); DIRECTIVE 2004/108/EEC OF THE EUROPEAN PARLIAMENT AND COUNCIL of 15 December 2004 regard-
ing the approximation of member state legislation relating to electromagnetic compatibility, repealing directive 89/336/EEC
According to the following harmonised standards: EN 61000-6-2:2001; EN 61000-6-3:2001+A11:2004
The product also complies, within the constraints of applicable parts, with the following standards:
EN 60335-1:2002+A1:2004+A11:2004+A12:2006+ A2:2006, EN 60335-2-103:2003, EN 13241-1:2003; EN 12453:2002; EN 12445:2002;
EN 12978:2003
Oderzo, 25 September 2008 Lauro Buoro (Managing Director)
WARNINGS: • All technical characteristics stated refer to an ambient temperature of 20°C (±5°C). • Nice S.p.a reserves the right to modify the product at any
timee, while maintaining the same functionalities and intended use.
Mains power supply MC424 Control units: 230 V~ ±10% 50 ÷ 60 Hz
MC424/V1 Control units: 120 V~ ±10% 50 ÷ 60 Hz
Max absorbed power 170 W
Emergency power supply for PS124 buffer batteries and for Solemyo solar kit
Maximum motor current: 3A (with a “level 6” current sensitivity cut in)
Service power output 24 V 200 mA maximum current (the voltage can vary from 16 to 33 V )
Phototest Output 24 V 100 mA maximum current (the voltage can vary from 16 to 33 V )
Flashing lamp output for flashing lamp 24 V , maximum power 25 W (the voltage can vary from 16 to 33 V )
Gate open indicator output for indicator lamps at 24 V maximum power 5 W (the voltage can vary from 16 to 33V )
or electric locks 12 V~ 25 W
STOP Input for NC contacts or constant resistance 8,2 KΩ +/- 25%
Working time automatic detection
Pause time programmable at 5, 10, 20, 40, 80 seconds
Discharge time programmable to 0, 0.3, 0.7, 1.3, 2 seconds
Leaf delay in open cycle programmable at 5, 10, 20, 30 and 40 % of working time
Leaf delay in close cycle automatic detection
1st motor output for Wingo WG4024 - WG5024
2nd motor output for Wingo WG4024 - WG5024
Max. cable length 230 V power supply 30 m
Solemyo solar power kit 3 m
motors 10 m
other inputs/outputs 30 m
flashing light 10 m
SCA 30 m
electric lock 10 m
aerial 20 m (recommended less than 3 m)
Radio receiver “SM” type coupling for receivers SMXI, SMXIS, OXI (Mode I and Mode II)
Temperatura di esercizio from - 20 to 50 °C
Protection rating IP 54 with enclosure intact
Dimensions (mm) 310 x 232 x H 122
Weight (kg) 4,1
TECHNICAL CHARACTERISTICS OF THE PRODUCT
