English – 18
EN
TECHNICAL SPECIFICATIONS
WARNINGS: • All technical specifications stated in this section refer to an ambient
temperature of 20°C (± 5°C). • Nice S.p.a. reserves the right to modify its products
at any time deemed necessary, while maintaining the same intended use and func-
tionality.
l General type: two independent access control systems, each composed of: sys-
tem a) - MORX decoder + 1 to 4 digital combination keypads (EDS / EDSI); sys-
tem b) - MORX decoder + 1 transponder card reader (ETP).
l Max cable length: decoder to reader/keypad = 10 m; with shielded cable = 30 m
l Memory capacity: 1 or 2 BM1000 cards (one card can hold up to 255 combina-
tions or cards).
l Power: preferably 24 VAC / DC, limits: 10 - 35 VDC, 12 - 28 VAC.
l Maximum power draw (with 4 keypads or 1 reader): 24 VDC = 70 mA; 24 VAC
= 200 mA; 12 VDC = 150 mA; 12 VAC = 300 mA
l Typical draw (one keypad): 24 VDC = 30 mA; 24 VAC = 80 mA; 12 VDC = 60
mA; 12 VAC = 100 mA
l Relay output contacts: max 500 mA and 48 VAC / DC
l Protection rating: IP 30
l Operating temperature: -20°C to 70°C
l Dimensions (mm): 98 x 42 h 25
l Weight: approx. 65 g
