Nice RDF-140-20 User Manual

6 – English
EN
RDF- 140-20 220-15* 290-15* 380-15 450-15 550-12 750-9,5
30 40
140 220 290 380 450 550 750
120 200 250 360 400 450 700
20 15 15 15 15 12 9.5
0.55 1.1 1.1 1.5 1.5 1.5 1.5
15 10-20 10-20 10-20 10-20 10 40
3x220 V / 3x380 V 60 Hz**
S 3 - 60%
5 x 1.5
-5°C ... +55°C
<70
IP 54
12.4 22 24 28.9 27.7 27.7 35
Technical data
Model
Shaft Ø (mm)
Max. torque (Nm)**
Rated torque (Nm)**
Output rpm**
Motor power (kW)
Limit switch rpm
Working voltage (V/Hz)
Duty Cycle
Connection cable (no. x mm
2
)
Operating temperature (°C)
Noise dB(A)
Protection rating (IP)
Weight (kg)
Model
Shaft Ø (mm)
Max. torque (Nm)
Rated torque (Nm)
Output rpm
Motor power (kW)
Limit switch rpm
Working voltage (V/Hz)
Duty Cycle
Connection cable (no. x mm
2
)
Operating temperature (°C)
Noise dB(A)
Protection rating (IP)
Weight (kg)
*
These models are not tested by TÜV-Nord
**
In case 60 Hz frequency, maximum and rated torque are decreased of about 7-12% and output speed is increase of about 14-15%.
NOTE: all the technical characteristics indicated refer to a temperature falling beetwen -5°C and +40°C. • Nice reserves the right to
change all the modications to the product it deems necessary at any time, but keeping the functions and intended use unaltered.
TECHNICAL SPECIFICATIONS
ANNUAL CHECK
Information for whoever carries out the checks
Gearmotor:
The mechanism is maintenance-free and it is provided with
permanent lubrication. Absolutely no rust must form on the output
shaft.
Fixings:
Make sure that the xing screws are all in the correct position and
in perfect condition.
Balancing by weights (e.g. in the sectional main doors):
The door must be balanced in all the positions (see the door
assembly instructions) when balancing is done with weights
according to the procedures prescribed by the standards.
Brake (if present):
During the annual check perfect brake operation is to be ascertained.
In the case of heavy wear of the brake pads, it is necessary to
replace the complete brake. Before replacement, disconnect the
cables connected to the electric card.
BGR 232 directive "Windows, doors and main doors with
mechanical operation" is applied. It can be obtained from the
National Insurance Institute for Industrial Accidents of your trade
association or from us on request.
Maintenance operations on windows, doors and main doors
with mechanical operation must be performed only by personnel
authorised by the company, having the necessary experience and
skills (BGR 232).
RDF- 850-10 1100-10 1400-7* 250-24* 350-24 500-24* 750-24* 950-24* 1250-24* 1400-24*
55 40 55
850 1100 1400 250 350 500 750 950 1250 1400
700 950 1250 230 310 450 650 850 1100 1250
10 10 7 24 24 24 24 24 24 24
2.2 2.2 2.2 1.1 1.5 2.2 2.2 3 4 5.5
10-40 10-40 10-40 10-40 10-40 10-40 10-40 10-40 10-40 10-40
3x220 V / 3x380 V 60 Hz
S 3 - 60%
5 x 1.5
-5°C ... +55°C
<70
IP 54
51.7 51.9 58 24.1 29.2 32.7 51.9 61 63 65
